HP 5920

103
Ste
p
Command Remarks
2. Configure a target host.
• (Method 1) Send traps to the target
host:
In non-FIPS mode:
snmp-agent target-host trap address
udp-domain { ip-address | ipv6
ipv6-address } [ udp-port
port-number ] [ vpn-instance
vpn-instance-name ] params
securityname security-string [ v1 | v2c
| v3 [ authentication | privacy ] ]
In FIPS mode:
snmp-agent target-host trap address
udp-domain { ip-address | ipv6
ipv6-address } [ udp-port
port-number ] [ vpn-instance
vpn-instance-name ] params
securityname security-string v3
{ authentication | privacy }
• (Method 2) Send informs to the target
host:
In non-FIPS mode:
snmp-agent target-host inform
address udp-domain { ip-address |
ipv6 ipv6-address } [ udp-port
port-number ] [ vpn-instance
vpn-instance-name ] params
securityname security-string { v2c | v3
[ authentication | privacy ] }
In FIPS mode:
snmp-agent target-host inform
address udp-domain { ip-address |
ipv6 ipv6-address } [ udp-port
port-number ] [ vpn-instance
vpn-instance-name ] params
securityname security-string v3
{ authentication | privacy }
Use either method.
By default, no target host is
configured.
3. (Optional.) Configure a
source address for
notifications.
snmp-agent { inform | trap } source
interface-type { interface-number |
interface-number.subnumber }
By default, SNMP uses the IP
address of the outgoing routed
interface as the source IP address.
4. (Optional.) Enable
extended
linkUp/linkDown
notifications.
snmp-agent trap if-mib link extended
By default, the SNMP agent sends
standard linkup/linkDown
notifications.
5. (Optional.) Configure
the notification queue
size.
snmp-agent trap queue-size size
By default, the notification queue
can hold 100 notification
messages.
6. (Optional.) Configure
the notification lifetime.
snmp-agent trap life seconds
The default notification lifetime is
120 seconds.
