HP 800 User Manual

80
DTC Connector Pinouts
8
DTC Connector Pinouts
DTC 25-pin direct connect RS-232
DTC 25-pin modem connect RS-232
1 - PGND -
2 - RD INPUT
3 - TD OUTPUT
7 - SGND -
8 - RTS OUTPUT
22 - CTS INPUT
1 - PGND -
2 - RD INPUT
3 - TD OUTPUT
4 - DCD INPUT
5 - GPO OUTPUT
6 - DTR OUTPUT
7 - SGND -
8 - RTS OUTPUT
20 - DSR INPUT
22 - CTS INPUT
