HP 800 User Manual

82
DTC Connector Pinouts
8
V.35 X.25 interface
103a TXA 21
103b TXb 42
104a RXa 20
104b RXb 41
113a TSEb/DTE 61
113b TSEb/DTE 62
114a TSEa/DCE 19
114b TSEb/DCE 40
115a RSEa/DCE 18
115b RSEb/DCE 39
105 RTS 57
106 CTS 4
109 DCD 6
108 DTR 58
107 DSR 46
125 RI 48
102 SG 9
102b RC 47
-50
-52
-22
-23
-24
-25
-26
-27
- CA 30
- CB 31
- CC 32
- CD 60
- PG SHIELD
