83
DTC Connector Pinouts
8
RS-232-D X.25 interface
103 TX 2
104 RX 3
113 TSE/DTE 24
114 TSE/DCE 15
115 RSE 17
105 RTS 4
106 CTS 5
109 DCD 8
108 DTR 20
107 DSR 6
125 RI 22
102 SG 7
101 SHIELD 1
