HP 800 User Manual

81
DTC Connector Pinouts
8
DTC 25-pin direct connect RS-423
DTC RJ-45 direct connect RS-232
DTC RJ-45 direct connect RS-423
1 - PGND -
8 - RTS OUTPUT
22 - CTS INPUT
15 - TXb OUTPUT
17 - TXa OUTPUT
19 - RXb INPUT
25 - RXa INPUT
1 - RD INPUT
3 - TD OUTPUT
4 - CTS INPUT
5 - RTS OUTPUT
6 - SGND -
1 - RXa INPUT
2 - RXb INPUT
3 - TXa OUTPUT
4 - CTS INPUT
5 - RTS OUTPUT
6 - TXb OUTPUT
