Instrument State Keys
P
I NSTRUME
11
1
8
I NSTRUME
SHIFT
SAVE
PRESETSAVE
PRESET
ADDRESSADDRESS
cl
LOCAL
NT STATE
PRESET
MODE
r,,,,,,l
SPECIAL
ALT
n
LII
MSG
pg42ab
Figure g-1. Instrument State Group
Registers 1-9 can be used to store instrument states. There is another
register used to store the
user-dehned
Preset instrument state.
The current instrument state is also saved continually in another register. All
11 registers are battery-backed-up, and contain the factory-defined preset
values until overwritten by other data. When power is turned on, the
instrument performs some self-tests and then returns to the last state’before
power was turned off. The current firmware revision, language mode, and
HP-B address are displayed in the
l&character
MARKER/SWEEP/STATUS
area; for example, Fw A. 01.00 SCPI 19
8-2
