HP 83751A - Spectral Purity; Residual FM (0.05 to 15 Khz Bandwidth)

I
-
Specifications and Options
Spectral Purity
Single-Sideband Phase Noise
-50
-70
N
t
-90
CL110
u
-130
-150
100 IK
10K
IOOK 1M IOM
Offset From Carrier
pg429ab
Figure 17.3. Typical Phase Noise (10 GHz Carrier)
Residual FM (0.05 to 15 kHz bandwidth)
Residual FM: 1 kHz RMS in CW mode
Residual FM is typically < 10 kHz in unlocked FM mode.
17-12
