To check the output power
1. Connect the equipment as shown.
POWER METER
SYNTHESIZED SWEEPER
I
SENSOR
RF OUTPUl
POWER SENSOR ADAPTER
pg427ob
Figure 1-2. Connections for Checking Output Power
2. Press (PRESET_).
3. Press ccw) (ZiJ CGHz/dB(mL).
4. Press POWER LEVEL) and enter the specified power for the CW frequency
you set. Refer to the following table. Terminate the power level entry by
pressing (GHz/dB(mZ).
Instrument
Maximum leveled
Power Specification
HP 83751Ml3752A”
HP 837518”
HP 837528”
< 2 GHz
1 2 GHz
+I0 dBm
+I7 dBm
+I6 dBm
+I7 dBm
1 * Option IEI lstep attenuetorl, reduce by 1 dB.1
l-8
