I
-
I
-
Error Messages
SCPI Error Messages
Internal
Hardware
Errors
501
502
503
504
505
-300, “Device specific error;V/GHz DAC Out Of
Range(501)”
-2
11, “Trigger ignored;Trigger Immediate
Ignored(502)”
-211,
“Trigger ignored;Sweep Trigger Immediate
Ignored(503)”
-213,
“Init
ignored;Init Immediate
Ignored(504)”
-211, “Trigger ignored;Group Execute Trigger or *TRG
Ignored(505)”
Hardware
Configuration
Errors
601
-311,
“Memory
Error;Not
Able to Recall From EEPROM: Default
Used(601)”
More that a single bit error has been detected when recovering
calibration data from EEPROM. Thus, it could not be used. Default
calibration data is used instead.
602
-311,
“Memory Error;EEPROM Failure. Calibration data could
not be
saved(602)”
603
604
605
Calibration could not be stored in EEPROM. EEPROM have been
detected to have failed.
-311,
“Memory Error;RECALL Was Aborted. Presetting to Fix
Instrument State
Used(603)”
-311,
“Memory Error;SAVE/RECALL Registers Corrupted.
Registers
Erased(604)”
-311,
“Memory Error;No Data In SAVE/RECALL Registers.
RECALL
Ignored(605)”
16-32
