Performing the Operator’s Check
To check the maximum leveled power
\
UNLEV
ANNUNCLATOR
’ tiEARS
00
0 0 000 0 00000
000 0 000 0 00000
00
0 0 000 0 00000
0
0
:a:: -* 0 0 0’0 000000 0
pg426ob
Figure l-l. The UNLEV Annunciator location
For HP 83752B Instruments Only.
The HP 83752B sweepers have a power specification that is split at 2 GHz.
7. Press the following keys to set a sweep range of 2 GHz to 20 GHz and a
power level of 17 dBm (or 16 dBm for instruments with option 1El):
(START_) 0 @iqGqLq)
[POWER mm) 117) (or [16)) [GHz/dB(mL)
8. Press @NGLE TRIG_) and make sure the UNLEV annunciator does not come
on at any point during the sweep. (If the annunciator comes on, it
indicates the instrument is unleveled.) The UNLEV annunciator is located
in the POWER display area. (See Figure l-l.)
l-7
