I
-
Modulation Keys
PERIOD
PLUSE
,$
I
1
MODE
0
WIDTH
UNLOCKED
FM
0
pg44ab
Figure
10-l.
The Modulation Group
AM and FM modulation is obtained by means of an external signal being
applied to the rear-panel AM INPUT or FM INPUT BNC connectors. There are
2 FM modes: AC (locked) and DC (unlocked).
NOTE
In the
DC
(unlocked\ mode, frequency accuracy will he degraded as a result of the synthesizer being
bypassed.
10-2
