Power Keys
(ALC MODE fi)
Source Module
Leveling
front panel. To obtain calibrated leveled power, the EXT
CAL adjustment should be made. (See EXT CAL .) The
EXT ALC LED is turned on. The displayed message is:
ALI::= pi:ii..jel- Met. et-.
The ALC point is inside an external source module
(millimeter head). The displayed message is
HLC:=Sourc~Modu 1 e. This mode is selected automatically
when the @Z’ZK) key is pressed with a millimeter head
connected.
Associated SCPI Commands
POWer:ALC:SOURce INTernal
POWer:ALC[:STATe] ON
POWer:ALC:SOURce DIODe
Sets the ALC mode to internaL
Turns ALC on.
Sets the ALC sour@ sebtion swkch
to external detector Swing.
POWer:ALC:SOURce PMETer Sets the ALC source selection swkch
to external power meter leveing.
POWer:ALC:SOURce MMHead Sets the ALC source se&on swkch
to ekternal mflimeter head b&ng.
POWer:ALC[:STATe] OFF Selects untkveLed mode.
Associated 8350 Commands
Al
Sets ALC mode to internaL
A2 Sets ALC mode to external detector
hhg.
A3
Sets ALC mode to external power
meter lebvling.
13-8
