I
-
Special Functions
14 - FM SENSITIVITY
14-FM
This function allows you to choose the FM sensitivity of your instrument:
either -6 MHz/V or -20 MHz/V. The factory preset default value is
SENSITIVITY -20 MHz/V
NOTE
The FM sensitivity will change from the nominal -6 or -20 MHz/V when a millimeter source module
is connected to the sweeper. Refer to the table below for the actual FM sensitivity respective to the
source module used.
Table 15-2. FM Sensitivity When Using Source Modules
Source
Module
Actual FM Sensitivity When Sweeper is Set to:
-6 MHzlVolt
-20 MHzlVolt
HP 83554 1x21
-12 MHz!‘.’
-40 MHz!‘,’
HP 83555 1x31
-18 MHziV
-60MHz/V
HP 83556 1x31
-18MHz/V
-60MHz/V
HP 83557 1x41
-24 MHzN
-80MHz/V
HP 83558 1x61
-36 MHz/‘.’
-120 MHz/V
Associated SCPI Commands
FM:SENSitivity -6 MHz/V
Sets the FM senskiiky to -6
MHfl
FKSENSitivity -20 MHz/V Sets the FM senskivky to -20
MHfl
15-19
