I
-
Specifications and Options
Modulation
FM
ACYLocked mode:
Rates: 50 kHz to 10 MHz
Maximum deviation: same as unlocked mode up to 25 times the rate
DC/unlocked mode:
Rates: DC to 10 MHz
Maximum deviation:
DC to 100 Hz rates: f75 MHz
100 Hz to 1 MHz rates: f 7 MHz
1 MHz to 2 MHz rates: f5 MHz
2 MHz to 10 MHz rates: f 1 MHz
Sensitivity: -6 or -20 MHz/V (See Chapter 15, “Special finctions, “for
FM sensitivity with millimeter head use.)
Input impedance: 1 kohm
17-14
