Getting Started
Entering Measurement Parameters
Entering Frequency
Range
1. Press the
(FREQ)
key to access the frequency
softkey
menu.
3.
To change the low end of the frequency range to 10 MHz, press
St&
Ilo)MHz.
3.
‘lb change the high end of the frequency range to 900 MHz, press Stop
(900)
MHZ.
4.
You can also set the frequency range by using the Center and Span
softkeys. For instance if you set the center frequency to 160 MHz and the
span to 300 MHz, the resulting frequency range would be 10 to 310 MHz.
NOTE
When entering frequencies, be sure to terminate Your numeric entry with the appropriate softkey to
obtain the correct units. If you use the (ENTER) key to terminate a frequency entry, the units
default to Hz.
The default displayed frequency resolution is kHz. You can change the resolution by pressing
IFREQ)
Disp
Freq
ReaoluIAon
, and then selecting a new resolution.
2-7
-
