HP A5800 Series Installation Guide

103
Product
Code
Module description
Central
wavelength
(nm)
Cable/fiber
diameter
(µm)
Multimode
fiber modal
bandwidth
(MHz × km)
Max
transmission
distance
160
220 m (721.78
ft)
JD119B
HP X120 1G SFP LC LX
transceiver
1310
9/125
N/A
10 km (6.21
miles)
JD061A
HP X125 1G SFP LC
LH40 1310nm
transceiver
1310
9/125
N/A
40 km (24.86
miles)
JD062A
HP X120 1G SFP LC
LH40 1550nm
transceiver
1550
9/125
N/A
40 km (24.86
miles)
JD063B
HP X125 1G SFP LC
LH70 Transceiver
1550
9/125
N/A
70 km (43.50
miles)
Table 22 10 Gbps SFP+ transceiver modules available for the SFP+ ports
Product
Code
Module
description
Central
wavelength
(nm)
Fiber
diameter
(µm)
Multimode
fiber modal
bandwidth
(MHz × km)
Max transmission distance
JD092B
HP X130 10G
SFP+ LC SR
transceiver
850
50/125
2000
300 m (984.25 ft)
500
82 m (269.03 ft)
400
66 m (216.54 ft)
JD093B
HP X130 10G
SFP+ LC LRM
transceiver
1310
62.5/125
200
160
220 m (721.78 ft)
JD094B
HP X130 10G
SFP+ LC LR
transceiver
1310
9/125
N/A
10 km (6.21 miles)
Table 23 SFP+ cables available for the SFP+ ports
Product
code
Cable description
Cable length
JD095B
HP X240 10G SFP+ SFP+ 0.65m DA Cable
0.65 m (2.13 ft)
JD096B
HP X240 10G SFP+ SFP+ 1.2m DA Cable
1.2 m (3.94 ft)
JD097B
HP X240 10G SFP+ SFP+ 3m DA Cable
3 m (9.84 ft)
JG081B
HP X240 10G SFP+ SFP+ 5m DA Cable
5 m (16.40 ft)
