HP A5800 Series Installation Guide

102
Product
Code
Module description
Central
wavelength
(nm)
Cable/fiber
diameter
(µm)
Multimode
fiber modal
bandwidth
(MHz × km)
Max
transmission
distance
JD063B
HP X125 1G SFP LC LH70
Transceiver
1550
9/125
N/A
70 km (43.50
miles)
Table 20 100 Mbps SFP transceiver modules available for the 100/1000 Base-X SFP ports
Product
code
Module description
Central
wavelength
(in nm)
Fiber diameter
(in µm)
Max transmission
distance
JD102B
HP X110 100M SFP LC
FX transceiver
1310
62.5/125
2 km (1.24 miles)
JD120B
HP X110 100M SFP LC LX
transceiver
1310
9/125
15 km (9.32 miles)
JD090A
HP X110 100M SFP LC
LH40 transceiver
1310
9/125
40 km (24.86 miles)
JD091A
HP X110 100M SFP LC
LH80 transceiver
1550
9/125
80 km (49.71 miles)
NOTE:
 To guarantee the functionality of the SFP ports, use only HP SFP transceiver modules.
 The SFP transceiver modules available for this switch series are subject to change over time. For the most up-to-
date list of SFP transceiver modules, consult your HP sales representative or technical support engineer.
 For the SFP transceiver module specifications, see HP A-Series Switches Transceiver Modules User Guide .
SFP+ port
All A5800 and A5820X switches but the A5800-48G-PoE+ (2 slots) and the A5800-48G-PoE+ TAA (2
slots), has fixed SFP+ ports. You can plug the SFP transceiver modules in Table 21, the SFP+ transceiver
modules in Table 22, and the SFP+ cables in Table 23 into the SFP+ ports as needed. You can use the
SFP+ ports as IRF physical ports to connect A5800 and A5820X switches in an IRF deployment.
Table 21 1000 Mbps SFP transceiver modules available for the SFP+ ports
Product
Code
Module description
Central
wavelength
(nm)
Cable/fiber
diameter
(µm)
Multimode
fiber modal
bandwidth
(MHz × km)
Max
transmission
distance
JD089B
HP X120 1G SFP RJ45 T
transceiver
N/A
Category-5
twisted pair
N/A
100 m (328.08
ft)
JD118B
HP X120 1G SFP LC SX
transceiver
850
50/125
500
550 m
(1804.46 ft)
400
500 m
(1640.42 ft)
62.5/125
200
275 m (902.23
ft)
