HP A5800 Series Installation Guide

58
Product
code
Module
description
Central
wavelength
(in nm)
Connector
Cable/fiber
specifications
Max transmission
distance
Transceiver
50/125 µm
multimode fiber
220 m (721.78 ft)
100 m (328.08 ft)
JD094B
HP X130 10G
SFP+ LC LR
Transceiver
1310
LC
9/125 µm
single-mode fiber
10 km (6.21 miles)
JD095B
HP X240 10G
SFP+ SFP+
0.65m DA
Cable
N/A
N/A
SFP+ cable
0.65 m (2.1 ft)
JD096B
HP X240 10G
SFP+ SFP+
1.2m DA
Cable
N/A
N/A
SFP+ cable
1.2 m (3.9 ft)
JD097B
HP X240 10G
SFP+ SFP+ 3m
DA Cable
N/A
N/A
SFP+ cable
3 m (9.8 ft)
JG081B
HP X240 10G
SFP+ SFP+ 5m
DA Cable
N/A
N/A
SFP+ cable
5 m (16.4 ft)
The following subsections describe several HP recommended IRF connection schemes, and all these
schemes use a ring topology.
IMPORTANT:
In these schemes, all physical IRF ports are located on the same side. If physical IRF ports are on
different sides, you must measure the distance between them to select an appropriate cable.
