161
73EB0549 A65D9E74 0F2953F2 D4F0042F
19103439 3D4F9359 88FB59F3 8D4B2F6C
2B
Exponent: 65537 (0x10001)
X509v3 extensions:
X509v3 CRL Distribution Points:
URI:http://4.4.4.133:447/myca.crl
Signature Algorithm: sha1WithRSAEncryption
836213A4 F2F74C1A 50F4100D B764D6CE
B30C0133 C4363F2F 73454D51 E9F95962
EDE9E590 E7458FA6 765A0D3F C4047BC2
9C391FF0 7383C4DF 9A0CCFA9 231428AF
987B029C C857AD96 E4C92441 9382E798
8FCC1E4A 3E598D81 96476875 E2F86C33
75B51661 B6556C5E 8F546E97 5197734B
C8C29AC7 E427C8E4 B9AAF5AA 80A75B3C
You can also use some other display commands, such as the display pki certificate ca domain and
display pki crl domain commands, to view detailed information about the CA certificate and CRLs. For
more information about the commands, see Security Command Reference.
Requesting a certificate from a CA server running Windows
®
2003 Server™
Network requirements
Configure PKI entity Device to request a local certificate from the CA server. See Figure 47.
Figure 47 Request a certificate from a CA server running Windows 2003 server
CA server
Internet
Host
Device
PKI entity
Configuration procedure
1. Configure the CA server.
• Install the certificate service suites.
From the Start menu, select Control Panel > Add or Remove Programs, and then select Add/Remove
Windows Components > Certificate Services and click Next to begin the installation.
• Install the SCEP add-on.
Because a CA server running the Windows 2003 server does not support SCEP by default, you must
install the SCEP add-on so that the switch can register and obtain its certificate automatically. After the
SCEP add-on installation is completed, a URL is displayed, which you must configure on the switch as the
URL of the server for certificate registration.
• Modify the certificate service attributes.
