ACL assignment configuration example
Network requirements
As shown in Figure 39, a host connects to the device’s port GigabitEthernet 1/0/1, and the device uses
RADIUS servers to perform authentication, authorization, and accounting.
Perform MAC authentication on port GigabitEthernet 1/0/1 to control Internet access. Make sure that
an authenticated user can access the Internet but not the FTP server at 10.0.0.1.
Use MAC-based user accounts for MAC authentication users. The MAC addresses are separated by
hyphens and in lowercase characters.
Figure 39 ACL assignment
Configuration procedure
NOTE:
Check that the RADIUS server and the access device can reach each other.
1. Configure the ACL assignment.
# Configure ACL 3000 to deny packets destined for 10.0.0.1.
<Sysname> system-view
[Sysname] acl number 3000
[Sysname-acl-adv-3000] rule 0 deny ip destination 10.0.0.1 0
[Sysname-acl-adv-3000] quit
2. Configure RADIUS-based MAC authentication on the device.
# Configure a RADIUS scheme.
[Sysname] radius scheme 2000
[Sysname-radius-2000] primary authentication 10.1.1.1 1812
[Sysname-radius-2000] primary accounting 10.1.1.2 1813
[Sysname-radius-2000] key authentication abc
[Sysname-radius-2000] key accounting abc
[Sysname-radius-2000] user-name-format without-domain
[Sysname-radius-2000] quit
# Apply the RADIUS scheme to an ISP domain for authentication, authorization, and accounting.
[Sysname] domain 2000
[Sysname-isp-2000] authentication default radius-scheme 2000
