Replacing a Pentium Processor (BA600 PCs)
Replacing a Pentium Processor (BA600 PCs)
1
Remove the cover. Refer to page 44.
2
Open the side panel of the PC and lay the system board flat. Refer to ”Removing the
Side Panel for Easy Access to System Board Components” on page 46.
3
Remove the old processor.
a
Using your nail, pull the retaining tab on one side of the socket outwards to
release the processor on one side.
b
Open the retaining tab on the other side and lift the processor out.
4
Install the new processor. Align the processor carefully above the slot, then push
the processor down firmly until it clicks into place.
5
Refer to page 48 for instructions on reinstalling the system board in your PC.
6
Replace the PC’s cover. Refer to page 45.
Caution
For your safety, disconnect the power cord and all external cables.
retaining tab
