5ā16 Maintenance and Service Guide
Removal and Replacement Procedures
ā
The integrated smart card bezel is included in the Miscellaneous
Plastics Kit, spare part number 345066-001.
5. Eject the smart card from the notebook using a flat-bladed
tool to press the small metal eject tab 1 to the left of the
smart card.
6. Remove the card from the slot 2.
Removing the Smart Card
Reverse the above procedure to install the integrated smart card.
