Removal and Replacement Procedures
Maintenance and Service Guide 5–31
5.15 LED Switch Cover
1. Prepare the notebook for disassembly (refer to Section 5.3).
2. Turn the notebook upside down with the rear facing you.
3. Remove the T8M2.0×6.0 screw that secures the LED switch
cover to the notebook.
Removing the LED Switch Cover Screw
Spare Part Number Information
LED switch cover 345063-001
