Removal and Replacement Procedures
Maintenance and Service Guide 5–43
4. Remove the bracket.
5. Remove the TouchPad 1 from the top cover.
6. Release the ZIF connector 2 to which the TouchPad cable is
attached and disconnect the cable 3.
Removing the TouchPad
Reverse the above procedure to install the TouchPad and bracket.
