HP Compaq nc8000

Screw Listing
Maintenance and Service Guide C–11
Torx T8M2.0×4.0 Screw Location
Table C-7
Torx T8M2.0×4.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Pewter 20 4.0 mm 2.0 mm 5.0 mm
Where used:
One screw that secures the fan assembly to the notebook
(documented in Section 5.22)
mm
