5–6 Maintenance and Service Guide
Removal and Replacement Procedures
4. Remove the battery pack by following these steps:
a. Turn the notebook upside down with the front facing you.
b. Slide and hold the battery release latch 1 toward the
back of the notebook.
c. Use the notch in the battery pack to slide the battery pack
to the right 2.
d. Remove the battery pack.
Removing the Battery Pack
Spare Part Number Information
Battery pack, 8-cell, 4.4 Wh, Li-Ion
Battery pack, 8-cell, 4.8AHR
338669-001
360663-001
