Memory Modules
Hardware and Software Guide 9–4
9. Insert the new memory module:
a. Align the keyed (notched) edge 1 of the module with the
tabbed area in the memory module slot.
b. With the module at a 45-degree angle from the surface of
the memory module compartment, press the memory
module 2 into the memory module slot until it is seated.
c. Press the module downward 3 until the retention clips
snap into place.
