Modem and Networking
Hardware and Software Guide 11–9
To connect the network cable:
1. Turn the tablet PC display-side up on a flat surface near a
network jack.
2. If the network cable has a noise suppression circuitry 1,
which prevents interference with TV and radio reception,
orient the circuitry end of the cable toward the tablet PC.
3. Plug the network cable into the RJ-45 (network) jack 2 on
the tablet PC.
4. Plug the other end of the cable into a network jack 3.
✎
Your tablet PC is equipped with LAN Power Save mode, which
enables you to conserve battery power. LAN Power Save mode
turns off the LAN device when the tablet PC is not connected
to
external power and the network cable is disconnected. For
more information, refer to
“Using LAN Power Save Mode” in
Chapter 2, “Power.”
