Page #15 background imageLoading...
Page #15 background image
12
Capacitors by distributor
Component
description
Location
Component
distributor
Distributor part number
EC 680uF 20% 35V
12.5*20 3000 hr 2A
C9102
C9130
C9103
Digi-Key
EGPA350ELL681MK20S
EC 680uF 20% 35V
12.5*20 3000 hr 2A
EGPA350ELL681MK20S
Connectors by manufacturer
Component
description
Location
identifier
Component
distributor
Distributer part number
HDMI CN501 RS SD-47151-001
(Molex)
DP CN502 Farnell DP1RD20JQ1
(JAE)
USB Type-C CN503 RS DX07S024JJ2R1300
JAE
RJ-45 CN103 tme LMJ34788114NWGY
AMPHENOL
USB 3.0 A CN117/CN118 RS 10117835-002LF
Amphenol ICC
Phone Jack CN610 NA Contact HP Support
USB 3.0 A CN154/CN153 RS 10117835-002LF
Amphenol ICC
NOTE: Rear cover and chassis need to be modified to hold connector. Connector may need
modifications to meet functional, safety and regulatory requirements accordingly if it doesn’t match
exactly.
You can purchase cables from the HP part store at https://partsurfer.hp.com/Search.aspx.
Internal and External Power Supplies are available for purchase from the following EU distributor: EET
https://www.eetgroup.com/en-eu/
NOTE: HP continually improves and changes product parts. For complete and current information
about supported parts for your product, go to https://partsurfer.hp.com/Search.aspx, select your
country or region, and then follow the on-screen instructions.

Other manuals for HP E34m G4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP E34m G4 and is the answer not in the manual?

HP E34m G4 Specifications

General IconGeneral
Panel typeVA
Color gamut99 %
Pixel pitch0.23175 x 0.23175 mm
Display diagonal34 \
Anti-glare screenYes
Display technology-
Native aspect ratio21:9
Maximum refresh rate75 Hz
Contrast ratio (typical)3000:1
Display number of colors16.7 million colors
Digital vertical frequency48 - 75 Hz
Digital horizontal frequency30 - 150 kHz
Display brightness (typical)400 cd/m²
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800, 1366 x 768, 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3440 x 1440
Tilt angle range-5 - 20 °
Panel mounting interface100 x 100 mm
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)185 W
Power consumption (standby)0.5 W
Power consumption (typical)65 W
Megapixel5 MP
RMS rated power10 W
Number of speakers2
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Product colorBlack
Market positioningBusiness
DisplayPort version1.2
Headphone connectivity3.5 mm
USB Type-A downstream ports quantity4
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)233 mm
Width (with stand)808.3 mm
Height (with stand)543.2 mm
Weight (with stand)11980 g
