Connector repair
This procedure includes HDMI, DisplayPort, USB Type-C, RJ-45 and USB 3.0 connectors.
The connectors are on the main board (board part number CBPR1R4H0Q3).
The connectors identifiers are as follows:
Connector Location
HDMI1 CN501
DP CN502
USB Type-C CN503
RJ45 CN103
USB 3.0 CN117
USB 3.0 CN118
This procedure includes Audio connector.
The connectors are on the Audio board (board part number AUPCPQB2).
The connector identifiers is as follows:
Connector Location
AUDIO CN610
Main Board
CN117
CN502
CN501
CN503
CN103
CN118
CN610
Audio Board
