HP E34m G4 User Manual



23

2) Lift the CN154、CN153 connector from the circuit board.
3) Place the new component on the circuit board. Be sure that it matches the footprint.
4) Solder the new component.
Function test
After repair, be sure to confirm that all functions are working.
Support and troubleshooting
The following table lists possible problems, the possible cause or each problem, and the recommended
solutions.
Table 4-1: Function test
Test item Operating description Tool used
HDMI test Confirm whether image displays and sound
plays correctly on the monitor.
Computer or DVD player
DP test Confirm whether image displays and sound
plays correctly on the monitor.
Computer or DVD player
USB-C test Confirm whether image displays and sound
plays correctly on the monitor
Computer or USB-C player
Audio test Change volume and balance to confirm whether
volume is smooth and loud enough.
Speaker
Table 4-2: Solving common problems
Problem Possible cause Solution
Screen is blank
or video is
flashing.
Power cord is disconnected. Connect the power cord.
Monitor is off. Power the power button.
NOTE: If pressing the
Power button has no
effect, press and hold the
power button for 10
seconds to disable the
Power button lockout
feature.
Video cable is improperly connected. Connect the video cable
properly.
System is in Auto-Sleep Mode. Press any key on the
keyboard or move the
mouse to inactivate the
screen blanking utility.

HP E34m G4 Specifications

General

Panel type	VA
Color gamut	99 %
Pixel pitch	0.23175 x 0.23175 mm
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	-
Native aspect ratio	21:9
Maximum refresh rate	75 Hz
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Digital vertical frequency	48 - 75 Hz
Digital horizontal frequency	30 - 150 kHz
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800, 1366 x 768, 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3440 x 1440
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	185 W
Power consumption (standby)	0.5 W
Power consumption (typical)	65 W
Megapixel	5 MP
RMS rated power	10 W
Number of speakers	2
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Product color	Black
Market positioning	Business
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB Type-A downstream ports quantity	4
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	233 mm
Width (with stand)	808.3 mm
Height (with stand)	543.2 mm
Weight (with stand)	11980 g
