HP E34m G4 User Manual

24

Video card is incompatible. Open the OSD menu and
select the Input menu. Set
Auto-Switch Input to Off
and manually select the
input or replace the video
card or connect the video
cable to one of the
computer’s on-board video
sources.
Image appears
blurred,
indistinct, or too
dark.
Brightness is too low. Open the OSD menu and
select Brightness to adjust
the brightness scale as
needed.
Check Video
Cable is
displayed on
screen.
Monitor video cable is disconnected. Connect the appropriate
video signal cable
between the computer and
monitor. Be sure that the
computer power is off
while you connect the
video cable.
Input Signal Out
of Range is
displayed on
screen.
Video resolution and/or refresh rate are set
higher than what the monitor supports.
Change the settings to a
supported setting.
The monitor
does not enter
into a low-power
sleep state.
The monitor's power saving control is disabled. Open the OSD menu and
select Power, select Auto-
Sleep Mode, and then set
auto-sleep to On.
“OSD Lockout”
is displayed
The monitor’s OSD lock function is enabled. Press and hold the Menu
button for 10 seconds to
disable the OSD Lockout
function.
Power Button is
Locked is
Displayed
The monitor's Power Button Lockout function is
enabled.
Press and hold the Power
button for 10 seconds to
unlock the power button
function.

HP E34m G4 Specifications

General

Panel type	VA
Color gamut	99 %
Pixel pitch	0.23175 x 0.23175 mm
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	-
Native aspect ratio	21:9
Maximum refresh rate	75 Hz
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Digital vertical frequency	48 - 75 Hz
Digital horizontal frequency	30 - 150 kHz
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800, 1366 x 768, 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3440 x 1440
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	185 W
Power consumption (standby)	0.5 W
Power consumption (typical)	65 W
Megapixel	5 MP
RMS rated power	10 W
Number of speakers	2
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Product color	Black
Market positioning	Business
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB Type-A downstream ports quantity	4
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	233 mm
Width (with stand)	808.3 mm
Height (with stand)	543.2 mm
Weight (with stand)	11980 g
