To start Refresh:
1. On the Start screen, point to the far-right upper or lower corner of the screen to display
the charms.
2.
Click Settings.
3.
Click Change PC settings in the bottom-right corner of the screen, and then select General
from the PC settings screen.
4. Under Refresh your PC without affecting your files, select Get started, and follow the
on-screen instructions.
Remove everything and reinstall Windows
Sometimes you want to perform detailed reformatting of your computer, or you want to remove
personal information before you give away or recycle your computer. The process described in this
section provides a speedy, simple way to return the computer to its original state. This option removes
all personal data, apps, and settings from your computer, and reinstalls Windows.
IMPORTANT: This option does not provide backups of your information. Before using this option,
back up any personal information you wish to retain.
You can initiate this option by using the f11 key or from the Start screen.
To use the f11 key:
1. Press f11 while the computer boots.
– or –
Press and hold f11 as you press the power button.
2. Select Troubleshoot from the boot options menu.
3. Select Reset your PC, and follow the on-screen instructions.
To use the Start screen:
1. On the Start screen, point to the far-right upper or lower corner of the screen to display
the charms.
2. Click Settings.
3. Click Change PC settings in the bottom-right corner of the screen, and then select General
from the PC settings screen.
4. Under Remove everything and reinstall Windows, select Get started, and follow the
on-screen instructions.
Windows 8
125

Table of Contents

Other manuals for HP EliteBook 2170p

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 2170p and is the answer not in the manual?

HP EliteBook 2170p Specifications

General IconGeneral
Bus typeDMI
SteppingL1
Tjunction105 °C
Processor cache3 MB
Processor cores2
Processor modeli5-3437U
System bus rate5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-3400 Mobile Series
Processor socketBGA 1023
Processor threads4
Processor codenameIvy Bridge
Processor frequency1.9 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency2.9 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)17 W
CPU multiplier (bus/core ratio)19
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® QM77 Express
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory- GB
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Card reader integratedYes
Total storage capacity500 GB
Compatible memory cardsSD
Number of HDDs installed1
Display surfaceMatt
Display diagonal11.6 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Intel segment taggingEnterprise
On-board graphics card ID0x166
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 4000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1200 MHz
Audio systemSRS Premium Sound Pro
3G standardsHSPA+
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version4.0
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile network generation3G
Charging port typeDC-in jack
Headphone connectivity3.5 mm
USB 2.0 ports quantity-
eSATA/USB 2.0 ports quantity0
Pointing deviceTouchpad
Operating system installedWindows 7 Professional
Form factorClamshell
Product typeLaptop
Product colorStainless steel
Housing materialMetal
Country of originChina
Processor codeSR0XE
Processor ARK ID71259
Processor package size31.0 x 24.0 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Battery capacity48 Wh
Battery life (max)8.25 h
Number of battery cells6
AC adapter power65 W
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth192 mm
Width292 mm
Height26.5 mm
Weight1330 g
