7.
Once the USB Recovery Disk On Key has booted, a dialog box will prompt, “Do you want to start
the System-Restore?” If data on the computer has not been backed up, use the tab key and select
No. The system will reboot. Back up the system data and repeat the previous steps. If no data
should be saved from the computer, use the tab key to select Yes. Press enter to begin the
recovery process.
8. After the files are copied to the system, follow the on-screen instructions.
Remove everything and reinstall SLED
Sometimes you want to perform detailed reformatting of your computer, or you want to remove
personal information before you give away or recycle your computer. The process described in this
section provides a speedy, simple way to return the computer to its original state. This option removes
all personal data, applications, and settings from your computer, and reinstalls the Linux operating
system.
IMPORTANT: This option does not provide backups of your information. Before using this option,
back up any personal information you wish to retain.
You can initiate this option by using the f11 key.
To use the f11 key:
Press f11 while the computer boots.
– or –
Press and hold f11 as you press the power button.
The following options are available:
Cancel/Reboot—Reboots the system. No recovery or restore activity is performed.
Recover/Repair System—This option repairs a system that is not working properly and preserves
user data.
Restore Factory System—This option restores the system back to the original factory state. User
data is not preserved.
Select an option and follow the on-screen instructions.
134 Chapter 7 Backup and recovery

Table of Contents

Other manuals for HP EliteBook 2170p

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 2170p and is the answer not in the manual?

HP EliteBook 2170p Specifications

General IconGeneral
Bus typeDMI
SteppingL1
Tjunction105 °C
Processor cache3 MB
Processor cores2
Processor modeli5-3437U
System bus rate5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-3400 Mobile Series
Processor socketBGA 1023
Processor threads4
Processor codenameIvy Bridge
Processor frequency1.9 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency2.9 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)17 W
CPU multiplier (bus/core ratio)19
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® QM77 Express
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory- GB
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Card reader integratedYes
Total storage capacity500 GB
Compatible memory cardsSD
Number of HDDs installed1
Display surfaceMatt
Display diagonal11.6 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Intel segment taggingEnterprise
On-board graphics card ID0x166
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 4000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1200 MHz
Audio systemSRS Premium Sound Pro
3G standardsHSPA+
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version4.0
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile network generation3G
Charging port typeDC-in jack
Headphone connectivity3.5 mm
USB 2.0 ports quantity-
eSATA/USB 2.0 ports quantity0
Pointing deviceTouchpad
Operating system installedWindows 7 Professional
Form factorClamshell
Product typeLaptop
Product colorStainless steel
Housing materialMetal
Country of originChina
Processor codeSR0XE
Processor ARK ID71259
Processor package size31.0 x 24.0 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Battery capacity48 Wh
Battery life (max)8.25 h
Number of battery cells6
AC adapter power65 W
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth192 mm
Width292 mm
Height26.5 mm
Weight1330 g
