4.
Release the ZIF connector to which the Media Card reader assembly cable is attached, and then
disconnect the Media Card reader assembly cable (3) from the Media Card reader assembly.
5. Remove the Media Card reader assembly.
Reverse this procedure to install the Media Card reader assembly.
RTC battery
Description Spare part number
RTC battery 651038-001
Before removing the RTC battery, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 56), and then remove the following components:
a.
Service cover (see
Service cover on page 58)
b. Hard drive (see
Hard drive on page 59)
c. WLAN module (see
WLAN module on page 62)
d. WWAN module (see
WWAN module on page 64)
86 Chapter 4 Removal and replacement procedures
