HP EliteBook 2170p Maintenance And Service Guide

149 pages

To Next Page

To Previous Page

Keyboard

For use in country/region Spare part

number

For use in country/region Spare part

number

Keyboard with backlight and pointing stick (includes keyboard cable, backlight cable, and pointing stick cable):

For use only on computer models equipped with the Windows

8 Standard and Professional operating system:

For use in the Netherlands 705614-B31

For use in Belgium 705614-A41 For use in Norway 705614-091

For use in Brazil 705614-201 For use in Northwest Africa 705614-FP1

For use in Bulgaria 705614-261 For use in Portugal 705614-131

For use in Canada 705614-DB1 For use in Romania 705614-271

For use in the Czech Republic

and Slovakia

705614-FL1 For use in Russia 705614-251

For use in Denmark 705614-081 For use in Saudi Arabia 705614-171

For use in France 705614-051 For use in Slovenia 705614-BA1

For use in Germany 705614-041 For use in South Korea 705614-AD1

For use in Greece 705614-151 For use in Spain 705614-071

For use in Hungary 705614-211 For use in Sweden and Finland 705614-B71

For use in Iceland 705614-DD1 For use in Switzerland 705614-BG1

For use in India 705614-D61 For use in Taiwan 705614-AB1

For use in Israel 705614-BB1 For use in Thailand 705614-281

For use in Italy 705614-061 For use in Turkey 705614-141

For use in Japan 705614-291 For use in the United Kingdom

and Singapore

705614-031

For use in Latin America 705614-161 For use in the United States 705614-001

For use only on computer models equipped with the Windows

7 operating system:

For use in the Netherlands 693363-B31

For use in Belgium 693363-A41 For use in Norway 693363-091

For use in Brazil 693363-201 For use in Northwest Africa 693363-FP1

For use in Bulgaria 693363-261 For use in Portugal 693363-131

For use in Canada 693363-DB1 For use in Romania 693363-271

For use in the Czech Republic

and Slovakia

693363-FL1 For use in Russia 693363-251

For use in Denmark 693363-081 For use in Saudi Arabia 693363-171

For use in France 693363-051 For use in Slovenia 693363-BA1

For use in Germany 693363-041 For use in South Korea 693363-AD1

Component replacement procedures

Other manuals for HP EliteBook 2170p

Manual10 pages

Specification29 pages

Getting Started Guide54 pages

Quickspecs28 pages

Questions and Answers:

Need help?

Do you have a question about the HP EliteBook 2170p and is the answer not in the manual?

HP EliteBook 2170p Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3437U
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3400 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	1.9 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	17 W
CPU multiplier (bus/core ratio)	19
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
Display surface	Matt
Display diagonal	11.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Intel segment tagging	Enterprise
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1200 MHz
Audio system	SRS Premium Sound Pro
3G standards	HSPA+
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile network generation	3G
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	-
eSATA/USB 2.0 ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Professional
Form factor	Clamshell
Product type	Laptop
Product color	Stainless steel
Housing material	Metal
Country of origin	China
Processor code	SR0XE
Processor ARK ID	71259
Processor package size	31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	48 Wh
Battery life (max)	8.25 h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR
