Item Component Spare part number
For use in Slovenia 693362-BA1
For use in South Korea 693362-AD1
For use in Spain 693362-071
For use in Sweden and Finland 693362-B71
For use in Switzerland 693362-BG1
For use in Taiwan 693362-AB1
For use in Thailand 693362-281
For use in Turkey 693362-141
For use in the United Kingdom and Singapore 693362-031
For use in the United States 693362-001
(3) Top cover (includes TouchPad):
NOTE: The top cover spare part kit includes the TouchPad but does not include a TouchPad cable. The TouchPad
cable is included in the Cable Kit, spare part number 693306-001.
For use on computer models equipped with a fingerprint reader 693317-001
For use on computer models not equipped with a fingerprint reader 694507-001
(4) Smart Card reader assembly (includes cable) 693312-001
(5) Media Card reader assembly
NOTE: The Media Card reader assembly spare part kit does not include a Media
Card reader assembly cable. The Media Card reader assembly cable is included in
the Cable Kit, spare part number 693306-001.
693353-001
(6) Fingerprint reader board (includes bracket and cable) 693349-001
(7) System board (includes replacement thermal material):
For use in all countries and regions except the People's Republic of China:
Equipped with an Intel Quad Core i7-3687U 2.10-GHz processor (SC turbo up to
3.30-GHz, 1600-MHz FSB, 4.0-MB L3 cache, 17 W) and the Windows 8 Standard
operating system
714520-501
Equipped with an Intel Quad Core i7-3687U 2.10-GHz processor (SC turbo up to
3.30-GHz, 1600-MHz FSB, 4.0-MB L3 cache, 17 W) and the Windows 8
Professional operating system
714520-601
Equipped with an Intel Quad Core i7-3687U 2.10-GHz processor (SC turbo up to
3.30-GHz, 1600-MHz FSB, 4.0-MB L3 cache, 17 W) and the Windows 7
operating system
714520-001
Equipped with an Intel Quad Core i7-3667U 1.80-GHz processor (SC turbo up to
2.90-GHz, 4.0-MB L3 cache, 17 W) and the Windows 8 Standard operating system
693360-501
Equipped with an Intel Quad Core i7-3667U 1.80-GHz processor (SC turbo up to
2.90-GHz, 4.0-MB L3 cache, 17 W) and the Windows 8 Professional
operating system
693360-601
Computer major components
27
