HP EliteBook 2170p Maintenance And Service Guide

Spare part number Description
641672-001 320-GB, 7200-rpm, 9.5-mm hard drive (does not include hard drive bracket, hard drive connector
adapter, or screws)
NOTE: The hard drive bracket, hard drive connector adapter, and screws are included in the
Hard Drive Hardware Kit, spare part number 693350-001.
651038-001 RTC battery
652972-001 2-GB memory module (PC3, 12800, 1600-MHz)
656839-001 HP notebook mini sleeve
657325-001 Broadcom 4313GN 802.11b/g/n 1×1 WiFi and 20702 Bluetooth 4.0 Combo Adapter
668969-001 HP hs2350 HSPA+ Mobile Broadband Module
670034-001 8-GB memory module (PC3, 12800, 1600-MHz)
670292-001 Intel Centrino Advanced-N 6235 WLAN module
671604-001 4-cell, 30-Wh, 2.00-Ah, Li-ion battery
676786-001 Atheros AR9462 802.11a/b/g/n 2×2 Bluetooth 4.0 Combo Adapter
683801-001 500-GB, 7200-rpm, 9.5-mm SED hard drive (does not include hard drive bracket, hard drive
connector adapter, or screws)
NOTE: The hard drive bracket, hard drive connector adapter, and screws are included in the
Hard Drive Hardware Kit, spare part number 693350-001.
685988-001 6-cell, 48-Wh, 2.20-Ah, Li-ion battery
693299-001 Antenna Kit (includes WLAN antenna cables and transceivers and WWAN antenna cables
and transceivers)
693300-001 Base enclosure (includes rubber feet, service cover release latch assembly, and battery release
latch assembly)
693301-001 Display enclosure
693302-001 Display bezel for use on computer models equipped with webcam
693303-001 Display bezel for use on computer models not equipped with webcam
693305-001 Display Cable Kit
693306-001 Cable Kit (includes audio board cable, SD Card reader board cable, and TouchPad cable)
693307-001 Heat sink (includes replacement thermal material)
693308-001 Fan (includes cable)
693309-001 Display Panel Support Kit (includes display enclosure with pre-installed WLAN antenna cables and
transceivers and WWAN antenna cables and transceivers)
693310-001 Display Hinge Cover Kit (includes left and right display hinges, left and right display hinge caps,
and left and right display hinge covers)
693311-001 Display clutch cover
693312-001 Smart Card reader assembly (includes cable)
693313-001 Microphone module
Sequential part number listing
37

HP EliteBook 2170p Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3437U
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3400 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	1.9 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	17 W
CPU multiplier (bus/core ratio)	19
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
Display surface	Matt
Display diagonal	11.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Intel segment tagging	Enterprise
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1200 MHz
Audio system	SRS Premium Sound Pro
3G standards	HSPA+
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile network generation	3G
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	-
eSATA/USB 2.0 ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Professional
Form factor	Clamshell
Product type	Laptop
Product color	Stainless steel
Housing material	Metal
Country of origin	China
Processor code	SR0XE
Processor ARK ID	71259
Processor package size	31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	48 Wh
Battery life (max)	8.25 h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	192 mm
Width	292 mm
Height	26.5 mm
Weight	1330 g
