HP EliteBook 2170p Maintenance And Service Guide

Spare part number Description
693358-501 System board equipped with an Intel Dual Core i5-3427U 1.70-GHz processor (SC turbo up to
2.70-GHz) and the Windows 8 Standard operating system for use in all countries and regions
except the People's Republic of China and the Ukraine (3.0-MB L3 cache, 17 W; includes
replacement thermal material)
693358-601 System board equipped with an Intel Dual Core i5-3427U 1.70-GHz processor (SC turbo up to
2.70-GHz) and the Windows 8 Professional operating system for use in all countries and regions
except the People's Republic of China and the Ukraine (3.0-MB L3 cache, 17 W; includes
replacement thermal material)
693360-001 System board equipped with an Intel Dual Core i7-3667U 1.80-GHz processor (SC turbo up to
2.90-GHz) and the Windows 7 operating system for use in all countries and regions except the
People's Republic of China and the Ukraine (4.0-MB L3 cache, 17 W; includes replacement
thermal material)
693360-501 System board equipped with an Intel Dual Core i7-3667U 1.80-GHz processor (SC turbo up to
2.90-GHz) and the Windows 8 Standard operating system for use in all countries and regions
except the People's Republic of China and the Ukraine (4.0-MB L3 cache, 17 W; includes
replacement thermal material)
693360-601 System board equipped with an Intel Dual Core i7-3667U 1.80-GHz processor (SC turbo up to
2.90-GHz) and the Windows 8 Professional operating system for use in all countries and regions
except the People's Republic of China and the Ukraine (4.0-MB L3 cache, 17 W; includes
replacement thermal material)
693361-001 11.6 in, HD, LED, AG, SVA display panel
693362-001 Keyboard with pointing stick for use on computer models equipped with the Windows 7
operating system in the United States (includes keyboard cable and pointing stick cable)
693362-031 Keyboard with pointing stick for use on computer models equipped with the Windows 7
operating system in the United Kingdom and Singapore (includes keyboard cable and pointing
stick cable)
693362-041 Keyboard with pointing stick for use on computer models equipped with the Windows 7
operating system in Germany (includes keyboard cable and pointing stick cable)
693362-051 Keyboard with pointing stick for use on computer models equipped with the Windows 7
operating system in France (includes keyboard cable and pointing stick cable)
693362-061 Keyboard with pointing stick for use on computer models equipped with the Windows 7
operating system in Italy (includes keyboard cable and pointing stick cable)
693362-071 Keyboard with pointing stick for use on computer models equipped with the Windows 7
operating system in Spain (includes keyboard cable and pointing stick cable)
693362-081 Keyboard with pointing stick for use on computer models equipped with the Windows 7
operating system in Denmark (includes keyboard cable and pointing stick cable)
693362-091 Keyboard with pointing stick for use on computer models equipped with the Windows 7
operating system in Norway (includes keyboard cable and pointing stick cable)
693362-131 Keyboard with pointing stick for use on computer models equipped with the Windows 7
operating system in Portugal (includes keyboard cable and pointing stick cable)
693362-141 Keyboard with pointing stick for use on computer models equipped with the Windows 7
operating system in Turkey (includes keyboard cable and pointing stick cable)
693362-151 Keyboard with pointing stick for use on computer models equipped with the Windows 7
operating system in Greece (includes keyboard cable and pointing stick cable)
Sequential part number listing
39

HP EliteBook 2170p Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3437U
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3400 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	1.9 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	17 W
CPU multiplier (bus/core ratio)	19
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
Display surface	Matt
Display diagonal	11.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Intel segment tagging	Enterprise
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1200 MHz
Audio system	SRS Premium Sound Pro
3G standards	HSPA+
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile network generation	3G
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	-
eSATA/USB 2.0 ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Professional
Form factor	Clamshell
Product type	Laptop
Product color	Stainless steel
Housing material	Metal
Country of origin	China
Processor code	SR0XE
Processor ARK ID	71259
Processor package size	31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	48 Wh
Battery life (max)	8.25 h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	192 mm
Width	292 mm
Height	26.5 mm
Weight	1330 g
