HP EliteBook 745 G2

Display assembly
NOTE: Non-touch displays are spared at the subcomponent level only. Touch displays are only spared as a
whole (touch display components are not spared).
In non-touch models, you can remove the raw display panel with the display assembly still connected to the
computer. For more information, see
Display panel (non-touch) on page 63.
The following section shows how to remove the raw display panel without removing the display assembly
from the computer. See the display section later in this chapter to remove internal components that require
that you remove the display assembly.
Description Spare part number
Display assembly, touch screen (whole assembly)
15 in, FHD, for use in HP EliteBook 755 models 774990-001
14 in, FHD, for use in HP EliteBook 745 models 777325-001
Display enclosure (non-touch models) (includes 4 transceivers with antennas)
Display bezel for use in HP EliteBook 745 models 779682-001
Display bezel for use in HP EliteBook 755 models 779686-001
Display hinges:
For use in HP EliteBook 745 models 730957-001
For use in HP EliteBook 755 models 730819-001
Antenna Kit (includes antenna cables and transceivers):
For use in HP EliteBook 745 models 780080-001
For use in HP EliteBook 755 models 780081-001
Before removing the display assembly, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Service door (see
Service door on page 47)
b. Battery (see
Battery on page 49)
c. Fan (see
Fan on page 74)
d. Keyboard (see
Keyboard on page 58)
e. Base enclosure (see
Internal base enclosure on page 68)
Remove the display assembly:
