6 Removal and replacement procedures for
Authorized Service Provider parts
CAUTION: Components described in this chapter should only be accessed by an authorized service provider.
Accessing these parts can damage the computer or void the warranty.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to
http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
Component replacement procedures
NOTE: Details about your computer, including model, serial number, product key, and length of warranty,
are on the service label at the bottom of your computer. See
Service Label on page 20 for details.
This chapter provides removal and replacement procedures for Authorized Service Provider only parts.
There are as many as 61 screws that must be removed, replaced, and/or loosened when servicing
the Authorized Service Provider parts. Make special note of each screw size and location during removal and
replacement.
Display panel (non-touch)
NOTE: Non-touch displays are spared at the subcomponent level only. Touch displays are only spared as a
whole (touch display components are not spared).
In non-touch models, you can remove the raw display panel with the display assembly still connected to the
computer. The following section shows how to remove the raw display panel without removing the display
assembly from the computer.
See
Display assembly on page 92 later in this chapter to remove internal components that require that you
remove the display assembly.
Description Spare part number
Display bezel
Display bezel for use in HP EliteBook 745 models 768808-001
Display bezel for use in HP EliteBook 755 models 773963-001
Display panel
(35.6 cm) 14.0 in LED, HD, AntiGlare (AG), SVA (1366×768), 200 nits (cd/m
2
), flat
768809-001
ENWW Component replacement procedures 63
