Hard drive
Description Spare part number
2.5 in HDD, SATA, 9.5 mm (does not include the hard drive bracket or screws)
1 TB, 7200 rpm, 9.5 mm 766644-001
2.5 in HDD, SATA, 7 mm (does not include the hard drive bracket or screws)
500 GB, 7200 rpm, 7 mm, SED 703268-001
500 GB, 7200 rpm, 7 mm 703267-001
500 GB, 5400 rpm, 7 mm, FIPS 730946-001
320 GB, 7200 rpm, 7 mm 634862-001
Hard Drive Hardware Kit (includes hard drive bracket and screws) 730793-001
2.5 in SSD (includes the hard drive bracket and screws)
256 GB, SATA III, Self-Encrypting Drive (SED), supporting Opal 2.0 768807-001
240 GB, SATA III 768805-001
180 GB, SATA III, SED, supporting Opal 1.0 768804-001
180 GB, SATA III 768803-001
128 GB, SATA III 768802-001
Before removing the hard drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the service door (see
Service door on page 47).
5. Remove the battery (see
Battery on page 49).
Remove the hard drive:
1. Turn the computer upside down on a flat surface.
50 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts ENWW
