HP EliteBook 745 G2 User Manual

2 External component identification
Display
Component Description
(1) WLAN antennas (2)* (select models only) Send and receive wireless signals to communicate with wireless local
area networks (WLAN).
(2) WWAN antennas (2)* (select models only) Send and receive wireless signals to communicate with wireless wide
area networks (WWAN).
(3) Internal microphones (2) Record sound.
(4) Webcam light (select models only) On: The webcam is in use.
ENWW Display 7

HP EliteBook 745 G2 Specifications

General

Graphics	AMD Radeon R6 Graphics
Display	14-inch diagonal HD (1366 x 768)
RAM	Up to 16 GB DDR3L
Storage	500 GB HDD
Operating System	Windows 8.1 Pro
Battery	3-cell Li-Ion
Dimensions	13.35 x 9.33 x 0.83 in (33.9 x 23.7 x 2.1 cm)
Ports	1 DisplayPort 1.2, 1 VGA, 1 RJ-45, 1 Headphone/microphone combo, 1 docking connector
Wireless	Bluetooth 4.0
