Keyboard
NOTE: For a detailed list of available keyboards, see Sequential part number listing on page 33.
Description Spare part number
Keyboard with pointing stick, no backlight 776474-xx1
Keyboard with pointing stick and backlight 776475-xx1
Before removing the keyboard, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the service door (see
Service door on page 47).
5. Remove the battery (see
Battery on page 49).
Remove the keyboard:
1. Loosen the two Phillips captive screws that secure the keyboard to the computer.
2. Rest and secure the partially open computer on its side.
58 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts ENWW
