HP EliteBook 745 G2 User Manual

Fan
Description Spare part number
Fan (includes cable) 730792-001
Before removing the fan, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the service door (see
Service door on page 47).
5. Remove the battery (see
Battery on page 49).
6. Remove the keyboard (see
Keyboard on page 58).
7. Remove the internal base enclosure (see
Internal base enclosure on page 68).
Remove the fan:
1. Loosen the two captive Phillips screws (1) that secure the fan to the base enclosure.
2. Disconnect the fan cable (2) from the system board.
3. Remove the fan (3).
Reverse this procedure to install the fan.
74 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts ENWW

HP EliteBook 745 G2 Specifications

General

Graphics	AMD Radeon R6 Graphics
Display	14-inch diagonal HD (1366 x 768)
RAM	Up to 16 GB DDR3L
Storage	500 GB HDD
Operating System	Windows 8.1 Pro
Battery	3-cell Li-Ion
Dimensions	13.35 x 9.33 x 0.83 in (33.9 x 23.7 x 2.1 cm)
Ports	1 DisplayPort 1.2, 1 VGA, 1 RJ-45, 1 Headphone/microphone combo, 1 docking connector
Wireless	Bluetooth 4.0
