HP EliteBook 745 G2 User Manual

Battery
Description Spare part number
3-cell, 50-Wh, 4.5-Ah 717376-001
3-cell, 24-Wh, 2.4-Ah 717375-001
Before disassembling the computer, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the service door (see
Service door on page 47).
Remove the battery:
1. Slide the battery release latches (1), and then lift the battery (2).
2. Remove the battery from the computer (3).
Install the battery by inserting it into the battery bay until you hear a click.
ENWW Component replacement procedures 49

HP EliteBook 745 G2 Specifications

General

Graphics	AMD Radeon R6 Graphics
Display	14-inch diagonal HD (1366 x 768)
RAM	Up to 16 GB DDR3L
Storage	500 GB HDD
Operating System	Windows 8.1 Pro
Battery	3-cell Li-Ion
Dimensions	13.35 x 9.33 x 0.83 in (33.9 x 23.7 x 2.1 cm)
Ports	1 DisplayPort 1.2, 1 VGA, 1 RJ-45, 1 Headphone/microphone combo, 1 docking connector
Wireless	Bluetooth 4.0
