HP EliteOne 800 G1 Service Manual

7. Two tabs secure both the left and right side panels to the computer. Press both tabs to disengage
the panel, and rotate the panel off the computer.
NOTE: The removal and replacement procedures are similar for both panels. Right panel (when
viewed from behind) shown in the following images.
To install the side panels, reverse the removal procedures.
Side panels
93

HP EliteOne 800 G1 Specifications

General

RAM	DDR3
Memory	DDR3
Graphics	Intel HD Graphics 4600
Ports	4x USB 3.0, DisplayPort, VGA, RJ-45
Wireless	802.11a/b/g/n Wi-Fi, Bluetooth 4.0
Dimensions	56.09 x 5.28 x 38.28 cm (22.08 x 2.08 x 15.07 in)
Processor	Intel Core i3/i5/i7 (4th Gen)
Weight	8.4 kg
