HP EliteOne 800 G1 Service Manual

Tilt/swivel stand (optional)
To remove the stand:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 34).
2. Push the release button (1) on the bottom of the stand and pull the back of the stand off (2) the
computer.
3. Push the base of the stand down (1), and loosen the captive screws securing the stand to the unit
(2).
38 Chapter 5 Removal and Replacement Procedures All-in One (AIO) Chassis

HP EliteOne 800 G1 Specifications

General

RAM	DDR3
Memory	DDR3
Graphics	Intel HD Graphics 4600
Ports	4x USB 3.0, DisplayPort, VGA, RJ-45
Wireless	802.11a/b/g/n Wi-Fi, Bluetooth 4.0
Dimensions	56.09 x 5.28 x 38.28 cm (22.08 x 2.08 x 15.07 in)
Processor	Intel Core i3/i5/i7 (4th Gen)
Weight	8.4 kg
