HP EliteOne 800 G1 Service Manual

Spare part
number
Description
724938-001 500 GB, hybrid SSD drive
727718-001 System board for use in models with NetClone
728559-001 128 GB Solid State Drive (SSD)
732490-001 Power button board
732493-001 Converter board
732503-001 Near field communication (NFC) NXP controller (use with NFC assembly kit, spare part number 733512-001)
732504-001 Card reader
732505-001 Intel Core i5, 4570s processor (3.4-GHz, 8-MB L3 cache)
732506-001 Intel Core i5, 4670s processor (3.3-GHz, 6-MB L3 cache)
732507-001 Intel Core i7, 4770s processor (3.1-GHz, 6-MB L3 cache)
732509-001 Standard stand assembly
732510-001 Webcam module for use in non-touchscreen models
733486-001 Sensor board assembly
733487-001 Heat sink (thermal module) for use with the processor (includes replacement thermal material)
733488-001 Heat sink (thermal module) for use with a discrete graphics board (includes replacement thermal material)
733489-001 Fan
733490-001 Power supply, 200W
733491-001 Hard drive cable (data and power assembly)
733492-001 Optical drive cable (data and power assembly)
733493-001 Converter board cable
733494-001 LVDS (display) reverse cable
733495-001 Backlight cable for use with LG and BOE display panels
733496-001 Backlight cable for use with Samsung display panels
733497-001 Touch control cable
733498-001 Touch drive reverse cable
733499-001 Antenna kit
733500-001 Front bezel
733501-001 Left I/O panel
733502-001 Upper rear access panel
733503-001 Lower rear access panel
733504-001 Rear I/O cover
733505-001 Right panel
Sequential part number listing
23

HP EliteOne 800 G1 Specifications

General

RAM	DDR3
Memory	DDR3
Graphics	Intel HD Graphics 4600
Ports	4x USB 3.0, DisplayPort, VGA, RJ-45
Wireless	802.11a/b/g/n Wi-Fi, Bluetooth 4.0
Dimensions	56.09 x 5.28 x 38.28 cm (22.08 x 2.08 x 15.07 in)
Processor	Intel Core i3/i5/i7 (4th Gen)
Weight	8.4 kg
