Bottom cover and rubber feet
Table 5-1 Bottom cover and rubber feet descriptions and part numbers
Description Spare part number
Bottom cover in pale gold nish L94026-001
Bottom cover in natural silver nish L94027-001
Bottom cover in nightfall black nish L94028-001
Rubber foot kit for natural silver nish L94024-001
Rubber foot kit for nightfall black nish L94025-001
Rubber foot kit for pale gold nish L94023-001
▲ Prepare the computer for disassembly (Preparation for disassembly on page 37).
To remove the bottom cover and rubber feet:
1. Peel the one rubber foot o the bottom of the computer (1).
2. Remove the two Phillips M2.5 × 5.0 screws from the rear of the computer (2).
3. Remove the two Phillips M2.5 × 5.0 screws from the front of the computer (3), and then remove the
bottom cover (4).
Reverse this procedure to install the bottom cover and rubber feet.
38 Chapter 5 Removal and replacement procedures for authorized service provider parts
